Stanley No. 71 Open-Throat Router Plane – The Classic Router for Grooves, Tenons, Inlays & Clean Joinery Bottoms

1. Introduction

The Stanley No. 71 Open-Throat Router Plane is one of the most iconic and essential hand tools for fine woodworking. Designed to clean, level, and refine the bottoms of grooves, dados, mortises, hinge recesses, and tenon cheeks, the No. 71 router plane offers unmatched precision and control.

Stanley No. 71 Router Planes for Sale on Ebay

With its open throat, dual cutter system, depth adjustment mechanism, and broad, stable sole, the No. 71 provides excellent visibility while routing, making it ideal for both stopped and through cuts. Its versatility has kept it popular among furniture makers, cabinetmakers, luthiers, patternmakers, and joiners for more than a century.

This article is a complete guide to the Stanley No. 71 Open-Throat Router Plane.

---

2. History of the Stanley No. 71 Plane

The No. 71 series is one of Stanley’s longest-running router plane lines.

Historical Highlights

• Introduced in the late 19th century
• Manufactured from 1894 to 1973
• Created to replace the traditional wooden “old woman’s tooth” router
• Produced in open-throat (Stanley No. 71) and closed-throat (Stanley No. 71½) versions
• First few years were japanned then nickel plated after 1888
• Shipped with two cutters: straight (standard) and spear-point (beading / corner cleanup)
• Sweetheart-era No. 71 planes are highly prized
• Later production included the 71½ (closed throat) and a 71 with fence

The No. 71 became a standard in woodworking shops—simple, dependable, and endlessly useful.

---

3. Manufacturer Background – Stanley Rule & Level / Stanley Works

Stanley’s router planes helped define precision joinery in the 20th century. The No. 71 reflects Stanley’s consistent focus on user-friendly mechanics and rugged durability.

Why the No. 71 Represents Classic Stanley Engineering

• Machined sole ensures flat, smooth routing
• Open throat improves visibility compared to earlier wooden router planes
• Robust cutter clamp system holds irons rigidly
• Depth adjustment wheel allows fine control
• Interchangeable cutters expand the plane’s functionality

The No. 71 remains a benchmark design still imitated by modern manufacturers.

---

4. Design and Features of the Stanley No. 71 Open-Throat Router Plane

The No. 71’s design focuses on visibility, stability, and precise depth control.

Specifications

• Body style: Open throat for visibility
• Width: Approx. 3″ across the sole
• Length: Approx. 4¾–5″
• Cutters: Usually two (sometimes three in later sets)
• Material: Cast iron body, steel cutters
• Depth adjustment: Threaded cutter-post mechanism

Core Features

• Open-throat design improves visibility for stopped and near-edge cuts
• Dual cutters (1/2″ straight & spear-point) cover most routing needs
• Fine-thread depth adjustment wheel
• Large, stable sole for leveling large recesses
• Removable fence (included on later models)
• Sole opening allows chips to clear efficiently
• Two handle posts for balanced grip

Why Woodworkers Love the No. 71

• Perfect for refining the bottoms of joints
• Excellent control and visibility
• Far more precise than chisels alone
• Works beautifully for hinge mortises, dados, and inlay cavities
• Compatible with modern aftermarket cutters

The No. 71 is a “must-own” tool for any hand-tool woodworker.

---

5. Usage & Applications

The No. 71 router plane excels anywhere precise depth control is needed.

Techniques for Best Performance

• Use the straight cutter for general groove and recess work
• Use the spear-point cutter for corners, cross-grain, and cleanup
• Start with shallow passes to avoid chatter
• Wax the bottom of the plane for smooth travel
• Register firmly to the surface while routing

The No. 71’s open throat gives a clear line of sight to your work for maximum accuracy.

Instructions for Using the Stanley No. 71 Router Plane

---

6. Restoration of a Stanley No. 71 Plane

The No. 71 is easy to restore and responds extremely well to tuning.

Typical Restoration Steps

1. Disassemble handles, cutter clamp, depth adjuster, and cutters
2. Remove rust using Evapo-Rust or a mild acid solution
3. Clean the sole and ensure it is flat
4. Polish the depth adjustment post for smooth operation
5. Sharpen cutters to razor sharpness
6. Refinish the wooden knobs lightly if needed
7. Lubricate all screws and moving parts
8. Reassemble and test on scrap wood

Optional Upgrades

• Hock or Veritas aftermarket cutters
• Replacement fence
• Polished sole for extremely smooth operation

Restoration Mistakes to Avoid

• Over-lapping the sole
• Rounding cutter edges
• Stripping the depth adjuster threads
• Removing japanning unnecessarily

With careful restoration, the No. 71 will perform like new.

Restoring a Stanley No. 71 Router Plane

There are two schools of thought about restoring old woodworking tools. Some say you shouldn’t take a tool back down to bare metal, but instead give it a thorough cleaning and preserve the history and patina from decades of use. Others suggest that it’s okay to make an old tool look brand new again by taking it down to bare metal, repainting, etc. Both have their place among woodworkers and tool collectors and neither is wrong, they’re just different perspectives.

My theory is less is more, but there is no single way to do this. I tend to lean more toward giving old tools a thorough cleaning rather than wire brushing or sand blasting a tool down to bare metal and making it look brand new. Having said that, I have done both, and on this web site I present information about both of these methods for tool restoration as there is a place for both.

Some Good Advice from Just Plane Fun about Cleaning Old Planes

---

7. Collectability & Value

The Stanley No. 71 remains extremely popular among both users and collectors.

Typical Value Range

• User-grade: $70–$110
• Good condition: $110–$165
• Sweetheart-era: $165–$225
• Complete boxed sets: $225–$325+

Value Factors

• Cutter originality and completeness
• Japanning condition
• Presence of the fence and depth stop
• Sweetheart or early-production markings
• Handle condition and hardware originality

A complete No. 71 is considered a premium vintage woodworking tool.

---

8. Finding Manuals, Parts & Additional Resources

Documentation Sources

• Stanley catalogs (1890s–1960s)
• Blood & Gore router-plane guides
• Stanley type studies
• Hand-tool woodworking forums

Replacement Parts

• New or reproduction cutters (Hock, Veritas)
• Veritas and Other New Router Planes
• Replacement fences
• Reproduction depth stops
• Donor planes for screws and clamps
• Stanley No. 71 Open Throat Router Plane Parts for Sale on Ebay

Because the No. 71 remained in production for decades, parts are generally accessible.

Additional Resources for the Stanley No. 71 Router Plane

Type Study Video for the Stanley 71 Router Plane – Just Plane Fun

---

9. Final Thoughts

The Stanley No. 71 Open-Throat Router Plane is a timeless, essential tool for fine woodworking. Whether cleaning the bottoms of joinery cuts, trimming inlays, or refining mortises, the No. 71 delivers precision, control, and reliability unmatched by most hand tools.

For woodworkers, it’s a must-have for accurate joinery.
For collectors, it’s an iconic and enduring piece of Stanley history.

Properly tuned, the No. 71 remains one of the best joinery-precision tools ever made.

---

Quick Reference Summary

Category	Details
Model	Stanley No. 71 Open-Throat Router Plane
Manufacturer	Stanley Rule & Level / Stanley Works
Era	Late 19th Century–Mid 20th Century
Length	~5″
Cutters	Straight & Spear-Point
Key Feature	Open throat for visibility & chip clearance
Best Uses	Dados, mortises, grooves, inlays, joinery bottoms
Rarity	Common but highly desirable
Typical Value	$70–$325+
Restoration Difficulty	Easy
Collectability	Very High
